Is part 227-0172 EN 45545-2 certified?

Yes, HAMM Mount manufactures part 227-0172 to EN 45545-2 fire safety standards, meeting HL2 and HL3 hazard level requirements for railway applications.

227-0172 - Caterpillar Sandwich Mount | HAMM Mount | OEM Replacement

Name: Caterpillar Sandwich Mount Part 227-0172
Brand: HAMM Mount
SKU: 227-0172
Availability: InStock
Rating: 4.8 (156 reviews)

Caterpillar Sandwich Mount - Part 227-0172

The 227-0172 is a sandwich mount (also known as shock mount, part 40-127) designed for Caterpillar soil compactors and vibratory rollers. Cross-reference part numbers include 143-4650. This mount uses a rubber-steel-rubber sandwich construction where rubber is vulcanized between steel plates, providing critical vibration isolation between the vibratory drum mechanism and the machine frame. Compatible with a wide range of CAT compactor models including CP-44, CP-54B, CP-64, CP-76, CS-56, CS-66B, CS-74, CS-76, CS-78B and the CB-334D/E paver series. Also fits CAT engines 3013 through C6.6. CAT compactors are standard equipment on US highway and road construction projects. HAMM Mount provides this aftermarket replacement at substantial savings versus OEM pricing.

Manufactured by HAMM Mount in our ISO 9001:2015 certified facility using advanced vulcanization technology and premium rubber compounds. Every unit undergoes multi-stage quality control including dimensional inspection, hardness verification, and load-deflection testing. Fire safety compliance per EN 45545-2 is verified for all railway applications.

Part 227-0172 | Caterpillar Sandwich Mount

Cross-Reference Part Numbers

143-4650, 1434650, 2270172, 40-127

This part may also be listed under the above alternate part numbers. All numbers refer to the same component.

Compatible Equipment & Models

CAT CB-334D/E, CB-335D, CP-44, CP-54B, CP-64, CP-76, CS-56, CS-66B, CS-74, CS-76, CP-563D, CS-78B; Engines: 3013, 3013C, 3014, 3024C, 3054, 3054B, 3054C, 3056, 3056E, 3116, 3126, C2.2, C4.4, C6.6

Technical Specifications

Property	Value	Standard
Part Number	227-0172	OEM Spec
Type	Caterpillar Sandwich Mount	-
Category	Engine Mounts	-
Dimensions	Sandwich-type rubber-steel-rubber construction	OEM Spec
Cross-Reference	143-4650, 1434650, 2270172, 40-127	OEM
Hardness	60 ± 5 Shore A	ISO 48-4
Tensile Strength	≥ 18 MPa	ISO 37
Elongation	≥ 350%	ISO 37
Compression Set	≤ 20%	ISO 815-1
Temperature Range	-45°C to +85°C	-
Fire Safety	EN 45545-2 HL2/HL3	Railway
Fatigue Life	> 2.5M cycles	Testing

Applications

Part 227-0172 is used in CAT roller/compactor drum and engine vibration isolation. Compatible models include: CAT CB-334D/E, CB-335D, CP-44, CP-54B, CP-64, CP-76, CS-56, CS-66B, CS-74, CS-76, CP-563D, CS-78B; Engines: 3013, 3013C, 3014, 3024C, 3054, 3054B, 3054C, 3056, 3056E, 3116, 3126, C2.2, C4.4, C6.6.

Railway & Transit: Metro systems, light rail, passenger trains, freight locomotives - primary suspension and bogie component applications
Construction Equipment: Excavators, bulldozers, wheel loaders by Caterpillar, Komatsu, Volvo
Mining & Heavy Industry: Mining trucks, material handling equipment, crushing and screening plants
Automotive: Engine mounts, transmission mounts for heavy trucks and passenger vehicles
Power Generation: Generator set mounting, industrial compressor isolation

Material & Compound

Base Polymer: Natural Rubber (NR) / SBR blend - optimized for vibration damping
Reinforcement: High-strength fabric layers and steel reinforcement plates
Protection: UV stabilizers, antiozonants, antioxidants for extended service life
Fire Safety: EN 45545-2 compliant fire retardant additives
Bonding: Proprietary rubber-to-metal bonding process (> 25 MPa pull-out strength)

Installation & Maintenance

Installation

Clean mounting surfaces - remove all oil, corrosion, and old rubber residue
Verify part number 227-0172 matches equipment specifications
Position component with correct orientation per installation drawings
Install hardware hand-tight, then torque in stages (30%, 60%, 100%) using cross-pattern
Re-check torque after 100 hours of operation

Inspection Schedule

Monthly: Visual check for cracks, tears, contamination
Quarterly: Torque verification, deflection measurement
Annually: Hardness test, comprehensive condition assessment

Quality & Certification

ISO 9001:2015 Quality Management System
EN 45545-2 Fire Safety (HL2 & HL3)
100% incoming material testing
SPC-monitored vulcanization process
Load-deflection testing per batch
Full traceability documentation available

Request Quote for Part 227-0172

Factory-direct pricing from HAMM Mount. Ships to USA, Canada & worldwide.

Get Free Quote

Frequently Asked Questions

What is part 227-0172?

Do you ship to the United States?

Yes, HAMM Mount ships to all 50 US states. Standard delivery is 7-10 business days via DHL or FedEx with full tracking and insurance. Express 3-5 day service is available for urgent orders.

What warranty is included?

Part 227-0172 carries a 24-month warranty against defects in materials and workmanship under normal operating conditions.

Can I get custom modifications?

Yes, HAMM Mount offers custom modifications including dimensional changes, alternative rubber compounds, special hardness grades, and additional certifications. Contact our engineering team.
